Full Stroke (mm) 量測行程

500,1000

Sensor

Wire - wound and hybrid potentiometer

Output Signal Mode 輸出信號模式

Resistance (Potentiometer)

Resolution 解析

Essentially infinite

Linearity 線性度

(standard class)±0.25%FS

(precision class)±0.1%FS ( ±1 count )

Repeatability 重覆性

±0.02%FS

Output Resistance 輸出電阻值

(standard class) 5K ohm ±10%FS

(precision class) 5K ohm±5%FS

Power Rating(watts)

[stroke 500 mm] 1 W at 40°C ; [stroke 1000 mm] 2 W at 40°C

Recommenden Input Voltage 輸入電壓

30V(AC/DC) Max., best voltage at 5 ~ 10VAC / VDC

Wire Specification 線徑規格

Material SUS304 with nylon coating

Diameter ; 0.6 mm ; Breaking load : 16 kg

Max. Travel Speed 最大往復速度

500 mm / sec.

Vibration 震動

10 Hz to 2000 Hz 10g

Cable 電線

Φ4.2 50 cm long

Weight 重量

< 600 g

Starting Torque on Spring 拉力

< 600 g

Operating Temp./ Humidity 操作溫度/濕度

-20°C ~ 70°C , RH 35 % ~ 90 % (No Condensation)

Storage Temp. 儲存溫度

-20°C ~ 80°C

Protection 保護等級

IP 50 Dust Proof (only for potantiometer housing)
